Troubleshooting of pillow toffee packaging machine in toffee production line

Troubleshooting of pillow packaging machine in toffee production line

1、 When the temperature is too high, the speed is too slow, and the heat resistance of the outer coating is poor, the seal will show signs of scorching and wrinkling. The repair method is to speed up, reduce the temperature, and replace the film material.

2、 When the cutterbed is too high or too low, the packing speed is too fast, and the push rod is not synchronized with the cutter, the cutter will cut on the product for maintenance. The method is to reduce the packing speed, adjust the height of the end seal parts, and make the center of the cutter at the middle of the product height.

3、 The color of the film color code is too light, the film drive slips, and the cut-off position deviates from the color code when the color code tracking is not turned on. At this time, the maintenance method is to refer to the packaging machine manual and adjust its sensitivity; In the man-machine dialogue interface, switch the tracking mode to "tracking switch"

4、 The solid state circuit breaker is burnt out, the temperature control meter is damaged, and the temperature meter cannot control the temperature when the thermocouple is damaged. The maintenance method is to replace the electric couple, replace the temperature control meter, and replace the heating element.

5、 If the speed is too fast, the thermal sealing of the inner layer of the film is poor. If the temperature is too low, the seal will leak or be insecure. The maintenance method is to slow down the speed, raise the temperature, and replace the film material.

6、 The air pressure is incorrect, the swing rod of the cylinder is loose, the heating temperature is low, and the heat seal is poor when the hot pressing roller and the drive roller are not parallel. The maintenance method is to adjust the parallelism, adjust the temperature and air pressure to make them tight.

The manufacturer of potato chip production line should pay attention to that the induction aviation plug must be inserted and the screw must be locked before the power is turned on; Do not use metal covers and containers, and do not press the start button on the metal table, otherwise the machine will be damaged; The manufacturer of the toffee production line should often touch the surface of the sensor head to check whether it is overheated. If it is found that it is hot, stop heating and wait for cooling before working; There will be high voltage in the pillow packaging body, and there is electricity on the bottom plate. Pay attention to it during maintenance to avoid personal danger.
